  Home - Products -HDMI Switch


4KDK305

5 port HDMI Switch 5x1

Introduction:
This HDMI Switch 5x1 V1.4 Support Full 3D 4Kx2K 340Mhz is an HDMI Switch with five inputs. It switch between the five input of the HDMI signal into one HD monitor or projector.It can optimize your home theater system to the best effect.It support full 3D format and 4Kx2K. Its video amplifier bandwidth can be up to 3.4Gbps/340MHz.

Description

Ultra HD 4Kx2K 5 Port HDMI Switch 5 in 1 out Switch HDMI 1.4 Switcher 4Kx2K with Remote Control

1.0 INTRODUCTION:Ultra HD 4Kx2K 5 Port HDMI Switch 5 in 1 out Switch HDMI 1.4 Switcher 4Kx2K with Remote Control

This HDMI Switch 5x1 V1.4 Support Full 3D 4Kx2K 340Mhz is an HDMI Switch with five inputs. It switch between the five input of the HDMI signal into one HD monitor or projector.It can optimize your home theater system to the best

effect.It support full 3D format and 4Kx2K. Its video amplifier bandwidth can be up to 3.4Gbps/340MHz.

2.0 FEATURES:Ultra HD 4Kx2K 5 Port HDMI Switch 5 in 1 out Switch HDMI 1.4 Switcher 4Kx2K with Remote Control

1. Switching is done via itself automatically when signal present on the ports.

2. Support HDCP protocol and applicable to source device and high definition display device such as DVD and HDTV which have HDMI or digital ports and

are compliant with HDCP protocol.

 3.Support high resolutions up to 3840*2160p

4. Support HDMI1.4

5. Extend the transmission distance and improve transmission signal.

6. Compatible with DVI by using HDMI TO DVI adapter.

7. Plug-and-play.

8. Convenient to connect multi-group input signals to display on one HDTV.

9. Save space. Allow several sources to use one high definition display device simultaneously.

10. Metal casing design and overall shielding without signal interference.

11. Select input port by hand freely.

12. LED indicates signal and power mode.

13. Power supply DC5V

3.0 SPECIFICATIONS:Ultra HD 4Kx2K 5 Port HDMI Switch 5 in 1 out Switch HDMI 1.4 Switcher 4Kx2K with Remote Control



HDMI version

HDMI 1.4

HDMI resolution

Up to 4K x 2K@30Hz, 1080p@60Hz&1080P 3D@24Hz

Support video color format

24/30/36 bit deep color

Support audio format

DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

Max bandwidth

340MHz

Max baud rate

3.4Gbps

Input cable distance

≤15m AWG26 HDMI standard cable

Output cable distance

≤20m AWG26 HDMI standard cable

Max working current

300mA

Power adapter format Input

AC (50HZ, 60HZ) 100V-240V; Output: DC5V

Operating Temperature

(-15 to +55°C) range

Dimension (L x W x H)

145x62.5x20 (mm)

Weight

215g

4.0 Package Contents:

1. 5x1 HDM Switch 4Kx2K ...................................................................1 Piece

2. 5V DC Power Adapter .........................................1 Piece(Optional- US,EU,AU,UK)

3. User Manual.........................................................................1 Piece

4. Remote Control.....................................................................1 Piece
