  Home - Products -HDMI Splitter


DK104C

HDMI Splitter 1x4

Introduction:
1x4 HDMI splitter distributes 1 HDMI source to 4 HDMI displays simultaneously.
It offers HD video solution for super market , shopping mall , HDTV, STB, DVD, projector factory, noise, data control center , information distribution, conference room presentation, education and training, corporation show room & home theater etc.

Description

  4 Port HDMI Splitter 1x4 HDMI Splitter 1920x1080 at 60Hz, Splitter 1 in 4 out HDMI 1.3 Divisor support 1080p,3D with HDCP

Instruction:

1x4 HDMI splitter distributes 1 HDMI source to 4 HDMI displays simultaneously.

It offers HD video solution for super market , shopping mall , HDTV, STB, DVD, projector factory, noise, data control center , information distribution, conference room presentation, education and training, corporation show room & home theater etc.



FEATURES:

1)Distributes 1 HDMI source to 4 HDMI Displays simultaneously.

2)Supports all the mandatory and several optional 3D formats

3)Supports High Definition Resolutions : 3D 1080p@24Hz,1080p @ 60HZ, 720p/1080i @ 120Hz

4) Compatible blue-ray,PS3 media format,fully support 3D display

5) EIDI Duration: 4 seconds



SPECIFICATION



Name of the product

HDMI Splitter 1x4

Signal Inputs/ Output

1 input 4 outputs

Housing Material & Color

Metal case & black

HDMI Connector

Type A 19 pin female

HDMI Version

HDMI 1.3b +HDCP1.2 (compatible HDCP1.1/1.0)

Support video format

DTV/HDTV:480i/576i/480p/576p/720p/1080i/1080p/3D video

Support audio format

DTS-HD Master Audio、Dolby true-HD etc.

Support video color format

Xv-YCC/deep color 36bit

Max baud rate

6.75Gps

Operating Frequency

Up to 225MHz

Max.cable extension

10 meters by 28AWGHDMI cable;15 meters by 26AWGHDMI cable

Power consumption

10 watts(Maximum)

Input/output DDC Signal

5 volts p-p (TTL)

Input/Output TMDS Signal

0.5~1.5 Volts p-p

Max working current

1.4A

Power adapter format... Input

AC(5OHZ,60HZ) 100V-240V; Output: DC5V

Operating Temperature range

(- 15 to + 55 Celsius degree)

Operating Humidity range

5 to 90% RH (No Condensation)

Size

95x61x21mm

NW.

117g



Packing List:

1.Main Adapter- HDMI Splitter 1x4

2.DC5V Power Supply

3.User Manual
